Transcript sylproof led 75w 1565mm t 6500k

Sylproof LED
SYLPROOF LED 75W 1565MM T 6500K
0047895
Range Features
•
Weather resistant LED Luminaire, 1565MM with Twin Lamp, 75W at 6500K. Reminisent of traditional T5
asthetic look and feel with all the benefits of LED. UV stablised polycarbonate cover with specially
designed linear prismatic len - softens and control the light optimises output and avoids yellow
staining. Highly efficient electronic driver included as standard. Smooth body finish, easy to handle and
install. Minimal maintainence with no intregral moving components. Through wiring effortlessly
achieved. IP65 and IK08 body durable for harsh locations. Professionally finished with Stainless Steel
brackets. Suspension compatible. As Sylproof LED. *Available from November 2015*.
PANORAMICA DEL PRODOTTO
Certificazioni
CE
Temperatura di colore (K)
6500
Colore
Grey
CRI (Ra)
80
Dimmerabile
Non-dim / not dimmable (switched only)
Codice EAN
5410288478951
Flusso luminoso (lm)
7246
Alloggiamento
Polycarbonate
Grado di protezione IK
IK08
Grado di protezione IP
IP65
Colore luce
Cool White
LOR (%)
100
Supporto
Surface or Suspended (with accessory)
Numero dell'ordine
0047895
Efficacia (classificata) (lm/w)
95.3421052631579
Durata media (classificata) (ore)
50000
Tecnologia
LED
Tensione (V)
220-240
Lampada inclusa
Integrated LED
Compatibile con lampadine di classe
energetica:
A++ A+
Consistenza del colore (SDCM)
6 Step
TABELLA DATI
Dati generali
Durata media (nominale) (ore)
50000
Certificazioni
CE
Tipo di componente di controllo
Electronic
Dimmerabile
Non-dim / not dimmable (switched only)
© Feilo Sylvania | Data di stampa: 09 ott 2016
Page 1 of 3
Sylproof LED
SYLPROOF LED 75W 1565MM T 6500K
0047895
Codice EAN
5410288478951
Ambiente
Internal/External
Classificazione dell'apparecchio di
illuminazione
Closed
Applicazione generale
Logistics and Industry
Alloggiamento
Polycarbonate
Supporto
Surface or Suspended (with accessory)
Numero dell'ordine
0047895
Nome prodotto
SYLPROOF LED 75W 1565MM T 6500K
Durata media (classificata) (ore)
50000
Tecnologia
LED
Compatibile con lampadine di classe
energetica:
A++ A+
Product features
What temperature Life is measured at
(°C):
Weather resistant LED Luminaire, 1565MM with Twin Lamp, 75W
at 6500K. Reminisent of traditional T5 asthetic look and feel with
all the benefits of LED. UV stablised polycarbonate cover with
specially designed linear prismatic len - softens and control the
light optimises output and avoids yellow staining. Highly efficient
electronic driver included as standard. Smooth body finish, easy
to handle and install. Minimal maintainence with no intregral
moving components. Through wiring effortlessly achieved. IP65
and IK08 body durable for harsh locations. Professionally finished
with Stainless Steel brackets. Suspension compatible. As Sylproof
LED. *Available from November 2015*.
25
Dati ottici
Temperatura di colore (K)
6500
CRI (Ra)
80
Tipo di distribuzione
Direct
Flusso luminoso (lm)
7246
Colore luce
Cool White
LOR (%)
100
Consistenza del colore (SDCM)
6 Step
Dati fisici
Colore
Grey
Finitura del diffusore
Clear
Materiale del diffusore
Polycarbonate
Altezza (mm)
91
Grado di protezione IK
IK08
Grado di protezione IP
IP65
Lampada inclusa
Integrated
Lunghezza (mm)
1565
© Feilo Sylvania | Data di stampa: 09 ott 2016
Page 2 of 3
Sylproof LED
SYLPROOF LED 75W 1565MM T 6500K
0047895
Finitura del riflettore
Polycarbonate Diffuser
Peso (kg)
3.1
Larghezza (mm)
123
Lampada inclusa
Integrated LED
Dati elettrici
Corrente di comando (mA)
1100
Protezione elettrica
CLASS I
Prova del filamento
850°C
Efficacia (classificata) (lm/w)
95.3421052631579
Classificazione Ta (°C)
-30°C to +30°C
Consumo energetico totale (W)
76
Tensione (V)
220-240
FOTOMETRIA
DISEGNI TECNICI
© Feilo Sylvania | Data di stampa: 09 ott 2016
Page 3 of 3
