Transcript LESSON 4: COMPUTE CISCO UCS

Certifications &
Resources
But first….
• Why UCS?
CCNA Data Center
Required Exam(s)
Recommended Training
640-911 DCICN
Introducing Cisco Data Center Networking (DCICN)
640-916 DCICT
Introducing Cisco Data Center Technologies (DCICT)
CCNP Data Center
642-999 DCUCI Implementing Cisco Data Center Unified Computing
642-997 DCUFI Implementing Cisco Data Center Unified Fabric
642-998 DCUCD Designing Cisco Data Center Unified Computing
642-996 DCUFD Designing Cisco Data Center Unified Fabric
642-035 DCUCT Troubleshooting Cisco Data Center Unified Computing
642-980 DCUFT Troubleshooting Cisco Data Center Unified Fabric
Suggested Lab Equipment
Todd Lammle Blog
CLN
Z Q Cert
Self Paced Learning on Lammle.com
GlobalNet UCS Classroom
Rack mount
Servers
NX-OS
6140-A
192.168.10.10
3
6140-B
192.168.10.10
4
Cluster
192.168.10.20
1
L
L
1
1
L
L
2
2
Fibre Channel
UCS C-Series
Fibre Channel
Eight
UCS 5108
w/ Eight B200
Blades
e
2
Fibre Channel Storage
Global Net Lab Equipment Types
5108 UCS Chassis
B200 UCS
Blade Server
Nexus 7010
Fabric
Interconnects
Fabric
Extender
MDS 9124 SAN
Switch
Nexus 2000
(2148T)
Nexus 5020
C200 UCS
Rackmount Server
UCS Emulator
Ucsdatacenter.com
Cisco Cloud Lab
Intro to UCS Terms
Data Center Networks
What is Fibre Channel?
•Fibre Channel is a Storage Area Network Used in Data Centers
– NOT Ethernet
– Different cables, ports, and switches
FC Ports
FC
FC
FC
HBA
Server
I/O Adapter
Switch
Array
Controller
Storage
Tape Device
Fibre Channel HBAs
Operating
System
Operating
System
I/O Subsystem
I/O Subsystem
TCP Driver
Fibre Channel
Driver
Ethernet NIC
Flow Control
Sequencing
Segmentation
Error Correction
HBA
Fibre Channel
HBA
Flow Control
Sequencing
Segmentation
Error Correction
Today Two Networks in Data Center
Today
LAN
SAN A
SAN B
Ethernet
Fibre Channel
Server Requirements
– Parallel LAN/SAN infrastructure
– Inefficient use of network
infrastructure
– 5+ connections per server to
higher adapter and cabling costs:
• Adds downstream port costs; capital
expenditures and operating expenses
• Each connection adds additional
points of failure in the fabric
– Longer lead time for server
provisioning
– Multiple fault domains to complex
diagnostics
– Management complexity:
firmware, driver patching, and
versioning
FC HBA
FC HBA
GE
GE
GE
GE
10/100
GE = Gigabit Ethernet
FC = Fiber Channel
HBA = Host Bus Adapter
Consolidating Ethernet with 10 GE to
the Server
10GE
 10/40 GE ethernet great reduces
the need for Ethernet Port.
 (1) 10GE port = (10) 1 GE ports!
GE = Gigabit Ethernet
Fibre Channel over Ethernet
FCoE
Benefits
 Mapping of FC frames
over Ethernet
 Enables FC to run on a
lossless Data Center
Ethernet network
Ethernet
Fibre
Channel
 Wire Server Once
 Fewer cables and adapters
and switches
 Software Provisioning of I/O
 Interoperates with existing
SANs
 No gateway—stateless
 Standard – June 3, 2009
Consolidation of LAN with Storage
Today
LAN
SAN A
I/O Consolidation with FCoE
SAN B
Enhanced Ethernet and FCoE
LAN
Ethernet
FCoE = Fibre Channel over Ethernet
SAN A
FC
SAN B
Non-UNIFIED I/O for Compute
• Consider a deployment of 64 blade servers in 8 chassis
with each blade having three 1Gb network interfaces
and 2 Fibre Channel interfaces and each chassis having
1 management interface
• 328 cables
• Typical Cisco UCS
– 36 cables
– More bandwidth
– Advantages
•
•
•
•
•
Management
Air flow
Less ports
Less heat
Less cooling
Before Cisco UCS…
After Cisco UCS….
CISCO UCS OVERVIEW
Cisco Unified Computing System overview
• Cisco Unified Computing System enables a
scalable, stateless Infrastructure
B420 M3
5108
B22 M3
Unified Computing System
• Unified fabric
• Unified management
• Service profiles
– Allows specification of server
– Provisions all aspects of server
• NICs, VLANs, QoS, UUIDs, WWN, VSAN, BIOS
• High density
• “Wire once” model
Simplification!
Physical Building Blocks
Unified Computing System
Manager
Embedded in Fabric Switch
Fabric Switch
20 Port 10Gb FCoE
40 Port 10Gb FCoE
Fabric Extender
Logically part of Fabric Switch
Inserts into Blade Enclosure
Enclosure
Flexible bay configurations
Logically part of Fabric Switch
Server Blade
Different blade types
Mix blade types within enclosure
Adapters
Three adapter options
Mix adapters within blade
Unified Computing System
LAN
Cisco Nexus
7000 series
10 Gigabit
Ethernet traffic
SAN A
SAN B
Cisco MDS 9000 family
fibre channel switches
Fibre channel
traffic
Cisco UCS 6100 series
fabric interconnects
Unified fabric
carrying IP and
FCoE traffic
Cisco UCS 2100 series
fabric extenders
UCS at a Glance
•
Fabric Interconnect
– Embedded UCS Manager
– Connectivity to IP Aggregation layer
– FC or FCoE connectivity to Storage or
SAN
– FCoE connectivity to blade server chassis
– Always installed in pairs
•
Blade Chassis
– (2) Fabric Extenders
– (8) slots per chassis
•
UCS Blade Servers
– B-series blades
• 12 – 32 Cores per blade
– Virtualization Interface Card (VIC)
34
Cisco UCS Fabric Interconnect
The BRAINS!
• Define a UCS Compute Domain
– Provides unified network connectivity
to chassis and blades
• 10 Gigabit Ethernet
• Fibre Channel over Ethernet (FCoE)
– IP connectivity to IP Aggregation Layer
– IP connectivity for NAS file storage
– Embedded UCS Management
35
Cisco UCS 6100 Fabric Interconnect
• The management and communication
backbone of a UCS System.
• Provides both network connectivity and
management capabilities to all attached
blades and chassis.
• Line-rate, low-latency, lossless 10 Gigabit
Ethernet and Fibre Channel over Ethernet
(FCoE) functions.
• Typically deployed in redundant pairs.
UCS – Blade Server Chassis
• Cisco UCS 5100 Series Blade Server
Chassis
– (4-8) Blades per chassis
– Fabric Extenders
– Redundant Power and Cooling
Cisco UCS 5108 Blade Server Chassis
• 8 x 10Gb external
• 8 x 10Gbps internal
 FCoE capable
 2 x 40Gbps/slot max
•
•
•
•
•
1.2 Tb throughput
Managed by 6100
Capable of Supporting 40 GB Ethernet Standards
Auto Discoverable by UCS Manager
Hot Pluggable: Fans, Power Supplies, Blades,
Fabric Extenders
Cisco UCS 2100 Fabric Extender
•
•
•
•
•
•
•
•
80 Gbps forwarding
Active/active with failover
8 x 10Gbps internal
SFP+ external ports
Jumbo frame
256 VLANs/VSANs
Low latency lossless 10Gbps
Managed by 6100
